Operation
RefertotheMaintenancesectionandperformallthe
necessaryinspectionandmaintenancesteps.
OperatingInstructions
HandleAdjustment
Theheightofthehandlecanbeadjustedfor
comfortableoperation.Standbehindthehandleto
determinetheheight.
1.Toadjustthehandleheight,positionthehardware
intooneofthreesetsofholesoneachsideofthe
mainframe.
2.Refertoguresbelowforthedifferenthandle
positions.Twoboltsmustbeusedintheliftlink
strapsatalltimes.
Figure6
FrontHandlePosition—LowestHeight
1.Trunnion
bracket–bottomhole
3.Mountingboltlocation
2.Liftlinkstraps4.Handlehardware–front
holes
Figure7
MiddleHandlePosition
1.Trunnion
bracket–bottomhole
3.Mountingboltlocation
2.Liftlinkstraps
4.Handle
hardware–middleholes
Figure8
RearHandlePosition—HighestHeight
1.Trunnionbracket–top
hole
3.Mountingboltlocation
2.Liftlinkstraps
4.Handlehardware–rear
holes
3.Adjustthetinegroundengagementleverasstated
intheAdjustmentssection.
OpentheFuelShut-OffValve
Rotatethevalveandalignwiththefuellinetoopen.
StartingtheEngine
1.Connectthewiretothesparkplug.
