Exmark LAZER Z E Series User Manual

Specications
Note:Motioncontrolleversareadjustableto
twoheights.
–Separatelevers,oneachsideoftheconsole,
controlspeedanddirectionoftravelofthe
respectivedrivewheels.
–Steeringiscontrolledbyvaryingtheposition
oftheleversrelativetoeachother.
–Movingmotioncontrolleversoutward(in
slots)locksthedrivesysteminneutral.
•PTOEngagementSwitch:Engageselectricclutch
(todrivebelt)whichengagesmowerblades.
•ParkingBrakeLever:Engages/Disengages
parkingbrake.
•DeckHeightAdjustmentLever:Setscutting
heighttodesiredposition.
•DeckLiftPedal:Footpedalthatliftsdeck.
•TransportLock:
–Latchingposition:Automaticallylatchesat
thetransportposition.
–Unlatchingposition:Deckdoesnotlatchat
thetransportposition.
Seat
•X-Series:
–AllModelsExcept“B1”:
Deluxesuspension(adjustablespring
suspension)seatwithhighback,padded
ip-uparmrests,andintegralsafetyswitch.
Seatheightremainsthesame.SeatIsolation
Systemforreducedvibration,toenhanceride
ofstandardseat.
–“B1”Models:
Standardseatwithhighback,foampadded
seatcushionwithinternalsuspension,
bolstering,two-tonecover,armrests,and
integralsafetyswitch.SeatIsolationSystem
forreducedvibration,toenhancerideof
standardseat.
•S-Series:
–“00”Models:
Standardseatwithhighback,extrawidefoam
paddedseatcushionwithinternalsuspension,
thickbolstering,two-tonecover,padded
ip-uparmrests,integralsafetyswitch,and
SeatIsolationSystemtoenhancerideof
standardseat.
–“A1”and“ A2”Models:
Deluxesuspension(adjustablespringsuspension)
seatwithhighback,paddedip-uparmrests,and
integralsafetyswitch.Seatheightremainsthe
same.SeatIsolationSystemforreducedvibration,
toenhancerideofstandardseat.
Optionalseataccessoriesforunitswithstandard
seats:
◊CustomRideSuspensionSystemtoenhance
standardseat.Addsapproximately3inches(7.6
cm)toseatheight.
•E-Series:
–“00”or“03”Models:
Standardseatwithhighback,foampadded
seatcushionwithinternalsuspension,
bolstering,two-tonecover,moldedip-up
armrests,andintegralsafetyswitch.
Optionalseataccessoriesforunitswith
standardseats:
◊CustomRideSuspensionSystem
toenhancestandardseat.Adds
approximately3inches(7.6cm)toseat
height.
◊Deluxesuspensionseatwithhighback,
(adjustablespringsuspension),padded
ip-uparmrests,andintegralsafetyswitch.
Addsapproximately1/2inch(1.3cm)to
seatheight.
◊SeatIsolationSystemforreduced
vibration,toenhancerideofstandard
seat,standardseatwithCustomRideSeat
SuspensionorDeluxeSuspensionSeat.
Addsapproximately1inch(2.5cm)to
seatheight.
–“B1”,“B2”,or“B3”Models:
Standardseatwithhighback,foampadded
seatcushionwithinternalsuspension,
bolstering,two-tonecover,paddedip-up
armrests,andintegralsafetyswitch.Seat
IsolationSystemforreducedvibration,to
enhancerideofstandardseat.
–“A1”,“A2”,or“ A3”Models:
Deluxesuspensionseatwithhighback,
(adjustablespringsuspension),armrests,and
integralsafetyswitch.Addsapproximately
1/2inch(1.3cm)toseatheight.
20

Exmark LAZER Z E Series Specifications

General

Engine Brand	Kawasaki
Transmission	Hydro-Drive
Deck Construction	Fabricated
Deck Material	10-gauge steel
Turning Radius	Zero
Cutting Width	52, 60, 72 inches
Category	Commercial
Type	Zero-Turn
Engine Type	4-cycle, V-Twin
Engine Options	Kawasaki
Speed	Up to 10 mph forward, 5 mph reverse
Warranty	5-year limited
Horsepower	23.5 - 27
Cutting Height	1.0 - 5.0 inches in 0.25 inch increments
