Exmark LAZER Z E Series User Manual

Maintenance
(Mayneedmoreoften
undersevereconditions.)
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
2.Drainoilwhileengineiswarmfromoperation.
3.Theoildrainhoseislocatedonrighthandside
ofengineattherear.Placepanundermachine
tocatchoil.Removeplugfromendofdrain
hose.Allowoiltodrainandreplaceoildrainplug.
Torqueplugto20-24ft-lb.
4.Replacetheoilltereveryotheroilchange.Clean
aroundoillterandunscrewltertoremove.
Beforereinstallingnewlter,applyathincoating
ofExmark4–CyclePremiumEngineoilonthe
surfaceoftherubberseal.Turnlterclockwise
untilrubbersealcontactsthelteradapterthen
tightenlteranadditional1/2to3/4turn.
5.Cleanaroundoilllcapandremovecap.Fillto
speciedcapacityandreplacecap.
6.UseoilrecommendedintheCheckEngineOil
Levelsection.DoNotoverll.Starttheengine
andcheckforleaks.
7.Wipeupanyspilledoilfromenginedeck
mountingsurfaces.
CheckHydraulicOilLevel
ServiceInterval:Every50hours
1.Stopengineandwaitforallmovingpartstostop.
Engageparkingbrake.
2.Waituntiltheunitcoolsbeforecheckingthe
hydraulicoil.
3.Slidetheseatalltheforwardtoaccessthecapson
theLHandRHhydrodrives.
4.Cleantheareaaroundhydraulicreservoircapand
removecap.
5.Wipethedipstickcleanandre-insertthecapback
intothehydro.Lightlytightenthecap.
6.Removethecapagainandcheckthelevelofthe
oilonthedipstick.SeeFigure34foroillevels.
Figure34
1.Full2.Add
Note:Theoillevelonthedipstickwillbe
incorrectiftheoilischeckedwhentheunitishot.
7.Ifthedipstickoillevelisatthe“add”markadd
ExmarkPremiumHydroOil.
8.Replacehydraulicreservoircapandtightenuntil
snug.DoNotovertighten.
CheckTirePressures
ServiceInterval:Every50hours
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
2.Checktirepressureindrivetiresandpneumatic
casters.
3.Inatedrivetiresandpneumaticcastersto13psi
(90kPa).
4.Semi-pneumaticcastertiresDoNotneedtobe
inated.
Note:DoNotaddanytypeoftirelinerorfoam
llmaterialtothetires.Excessiveloadscreatedby
foamlledtiresmaycausefailurestothehydrodrive
system,frame,andothercomponents.Foamlling
tireswillvoidthewarranty.
CheckConditionOfBelts
ServiceInterval:Every50hours
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
46

Exmark LAZER Z E Series Specifications

General

Engine Brand	Kawasaki
Transmission	Hydro-Drive
Deck Construction	Fabricated
Deck Material	10-gauge steel
Turning Radius	Zero
Cutting Width	52, 60, 72 inches
Category	Commercial
Type	Zero-Turn
Engine Type	4-cycle, V-Twin
Engine Options	Kawasaki
Speed	Up to 10 mph forward, 5 mph reverse
Warranty	5-year limited
Horsepower	23.5 - 27
Cutting Height	1.0 - 5.0 inches in 0.25 inch increments
