Exmark LAZER Z E Series User Manual

Operation
WARNING
Loadingamachineontoatrailerortruck
increasesthepossibilityoftip-overandcould
causeseriousinjuryordeath.
•Useextremecautionwhenoperatinga
machineonaramp.
•EnsurethattheROPSisintheupposition
andusetheseatbeltwhenloadingor
unloadingthemachine.Ensurethatthe
ROPSwillclearthetopofanenclosedtrailer.
•Useonlyafull-widthramp;donotuse
individualrampsforeachsideofthemachine.
•Donotexceeda15-degreeanglebetweenthe
rampandthegroundorbetweentheramp
andthetrailerortruck.
•Ensurethelengthoframpisatleastfour
times(4X)aslongastheheightofthetrailer
ortruckbedtotheground.Thiswillensure
thatrampangledoesnotexceed15degrees
onatground.
•Backuprampsanddriveforwarddown
ramps.
•Avoidsuddenaccelerationordeceleration
whiledrivingthemachineonarampasthis
couldcausealossofcontroloratip-over
situation.
g027996
5
1
2
6
Figure27
1.Full-widthrampin
stowedposition
4.Rampisatleastfour
times(4X)aslongasthe
heightofthetraileror
truckbedtotheground
2.Sideviewoffull-width
rampinloadingposition
5.H=heightofthetraileror
truckbedtotheground
3.Notgreaterthan
15degrees
6.Trailer
39

Exmark LAZER Z E Series Specifications

General

Engine Brand	Kawasaki
Transmission	Hydro-Drive
Deck Construction	Fabricated
Deck Material	10-gauge steel
Turning Radius	Zero
Cutting Width	52, 60, 72 inches
Category	Commercial
Type	Zero-Turn
Engine Type	4-cycle, V-Twin
Engine Options	Kawasaki
Speed	Up to 10 mph forward, 5 mph reverse
Warranty	5-year limited
Horsepower	23.5 - 27
Cutting Height	1.0 - 5.0 inches in 0.25 inch increments
