Exmark QUEST SP User Manual

ProductOverview
TreadWidth:(CentertoCenterof
Tires,Widthwise)
44inch
Deck
48inch
Deck
52inch
Deck
Drive
Wheels
36.0inches
(91cm)
36.0inches
(91cm)
37.2inches
(96cm)
Caster
Wheels
26.7inches
(68cm)
33.5inches
(85cm)
33.5inches
(85cm)
WheelBase:(CenterofCasterTireto
CenterofDriveTire)
44inch48&52inch
49.6inches(126cm)48.9inches(124cm)
CurbWeight:
44inchDeck48inchDeck52inchDeck
805lb(365kg)835lb(379kg)845lb(383kg)
TorqueRequirements
BoltLocation
Torque
SpindlePulleyNut130-160ft-lb(176-217
N-m)
BladeMountingBolt
(lubricatewithanti-seize)
50-60ft-lb(68-81N-m)
EngineMountingBolts
InTappedBosses
27-33ft-lb(37-45N-m)
EngineThroughMounting
Bolts
15-19ft-lb(20-25N-m)
Anti-ScalpRollerNyloc
Nut
27-33ft-lb(37-45N-m)
WheelLugNuts
70-90ft-lb(95-122N-m)
ClutchMountingBolt
(securedwiththreadlocker)
50-60ft-lb(68-81N-m)
DeckLiftFlangeBearing
Bolts
40-60in-lb(4.5-7.0N-m)
RolloverProtectionSystem
(RollBar)FrameMounting
Nuts
67-83ft-lb(91-112N-m)
RolloverProtectionSystem
(RollBar)Anti-Rack
MountingBolts
175-225in-lb(20-25N-m)
ProductOverview
Figure4
1.RolloverProtection
System(ROPS)
4.Motioncontrollevers
2.EngineControls(right
console)
5.Parkingbrake
3.Seatbelt6.Heightofcutadjustment
