Maintenance
Figure23
48and52InchDecks
1.Bladessidetoside2.Measurehere
Figure24
44InchDeck
1.Bladessidetoside2.Measurehere
7.Setanti-scalprollerstotopholesorremove
completelyforthisadjustment.
8.Settheheight-of-cutlevertothe3inch(76mm)
position.Placetwo“B”thickblocks(seeBlock
HeightandRakeTable)undertherearedgeofthe
cuttingdeckskirt;oneoneachsideofthecutting
deck.Placetwo“ A”thickblocksundereachside
ofthefrontedgeofthedeck,butnotunderthe
anti-scalprollerbrackets.
BlockHeightandRakeTable
Deck
Size
FrontBlock
Height“ A”
RearBlock
Height“B”
Rake“R”
44
2.58inches
(6.5cm)
2.82inches
(7.2cm)
1/8–3/8inch
(3.2–9.5mm)
48&
52
2.58inches
(6.5cm)
2.80inches
(7.1cm)
1/16–5/16inch
(1.6–7.9mm)
9.Carefullyrotatethebladessidetoside(Figure23
andFigure24).
10.Loosenthelevelingadjustlockingnuts(item1
Figure25)onallfourcornerssothatthedeckis
sittingsecurelyonallfourblocks.Makesurethat
theslackisremovedfromthedeckhangersand
thedeckliftfootleverispushedbackagainstthe
stop,thentightenthefourlevelingadjustlocking
nuts.
Figure25
1.Levelingadjustlocking
nuts
3.Deckhanger
2.Deckliftarm
11.Recheckthatblockstjustsnuglyunderthedeck
skirt.Makesureallattachmentboltsaretight
12.Continuelevelingthedeckbycheckingthe
front-to-rearbladeslope;refertoAdjustingthe
BladeSlope.
13.Recheckbladesforlevelnessandrepeatdeck
levelingprocedureifnecessary.
AdjustingtheBladeSlope
1.Checkthefront-to-rearbladelevelanytimeyou
installthemower.Ifthefrontbladetipisnot
“R”(seeBlockHeightandRakeTableinDeck
Leveling)lowerthantherearbladetip,adjustthe
bladelevelusingthefollowinginstructions:
2.Parkthemachineonalevelsurfaceanddisengage
thebladecontrolswitch.
3.Movethemotioncontrolleversoutwardto
theneutralposition,engagetheparkingbrake,
stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
4.Checktheairpressureofallfourtires.Ifneeded,
adjusttotherecommendedination;referto
36

Exmark QUEST SP Specifications
