Exmark QUEST SP - Motion Control Handle Adjustment

Maintenance
orwhenabrakecomponenthasbeenremovedor
replaced.
1.Drivethemachineontoalevelsurface.
2.Disengagethebladecontrolswitch(PTO),move
themotioncontrolleverstotheneutrallocked
positionandsettheparkingbrake.
3.Stoptheengine,waitforallmovingpartstostop,
andremovethekey.
4.Setupthemachinetobepushedbyhand(see
DriveWheelReleaseValvesintheOperation
section).
5.Raisethebackofthemachineupandsupportthe
machinewithjackstands.
CAUTION
Raisingthemowerdeckforserviceor
maintenancerelyingsolelyonmechanical
orhydraulicjackscouldbedangerous.The
mechanicalorhydraulicjacksmaynotbe
enoughsupportormaymalfunctionallowing
theunittofall,whichcouldcauseinjury.
DoNotrelysolelyonmechanicalorhydraulic
jacksforsupport.Useadequatejackstands
orequivalentsupport.
6.Engage/disengagethebrakeandcheckeachdrive
tiretomakesureeachbrakeengages/disengages.
7.Ifadjustmentisnecessary,loosenthejamnut
fromtheyokeonthesidethatneedsadjustment.
Removethehairpinandclevispin(seeFigure29).
Figure29
1.Hairpin3.Yoke
2.Clevispin
4.Jamnut
•AdjustingtheBraketoEngage:Shortenthe
linkagebyturningtheyokeclockwise.
•AdjustingtheBraketoDisengage:
Lengthenthelinkagebyturningtheyoke
counterclockwise.
8.Reinstalltheclevispinandhairpinandtighten
downthejamnut.Repeatstep6andreadjustif
necessary.
9.Whenadjustmentiscomplete,removethejack
standsorequivalentsupportandlowerthe
machine.
10.Placethemachineintothe“operating”position.
RefertotheDriveWheelReleaseValvessection
inOperation.
MotionControlHandle
Adjustment
Adjustingtheheight:
Themotioncontrolleverscanbeadjustedhigheror
lowerformaximumoperatorcomfort.
1.Removethehardwareholdingthecontrolleverto
thecontrolarmshaft(Figure30).
Figure30
1.Bolts
4.Controlarmshaft
2.Washer
5.Slottedhole
3.Controllever
2.Movethecontrollevertothenextsetofholes.
Securetheleverwiththehardware.
3.Repeattheadjustmentfortheoppositecontrol
lever.
AdjustingtheTilt
Themotioncontrolleverscanbetiltedforeoraftfor
maximumoperatorcomfort.
38
