Tech-note
tn202-2.doc - 10.01.2012
ePALM10 Product Manual
21
BLUE
SHIELD TRACE
N.C.
BLACK
RED
YELLOW
GREEN
BROWN
ORANGE
BLUE-BLACK
CY
AN
CY
AN-BLACK
RED
GREEN
Ferrite T
oroid
Figure 11 – Wiring
layout
4.3.1
Termination swi
tch
The ePALM has been d
esigned only
for connection at one of
the two ends of the
Profibus DP
network.
Figure 12 – Network to
pology
Profibus-DP requires te
rmination of the bus at
both end points; se
e the Profibus-
DP specifications for
details. The ePALM
includes the bus term
inator resistors. Make sur
e they are alway
s switched on.
ePALM10
Profibus DP
20
22
Table of Contents
Default Chapter
1
Table of Contents
1
1 Highlights
3
2 Technical Data
4
3 Operation
6
Enabling Switches
6
Indicators and Keypad
6
Battery Replacement
7
Power Supply and Grounding
8
Applicable Regulations
9
Installation Environment
9
Cleaning Faceplates
10
Getting Started
10
Serial Communication
10
Ethernet Communication
10
Troubleshooting
10
4 Connections
11
Serial Communication - Types -0061 and -0062
11
Using Optional Fieldbus Modules
14
Connecting the Epalm to the Simatic S7 MPI Network
15
Ethernet Communication - Type -0066 and -0068
16
Profibus DP Communication - Type -0067 and -0069
19
Termination Switch
21
Programming Connector
22
5 Accessories
23
