Exor ePALM10 User Manual

Tech-note
tn202-2.doc - 10.01.2012
ePALM10 Product Manual
4
2 Technical data
Display
Type Transflective LCD
monochrome
Resolution 120x64 pixel
Active display area 66x33 mm
Backlight LED
Dimming -
Contrast Software
Memory
User memory 512 KB Flash
User memory
expansion
-
Front panel
Touch screen -
Function keys 9
System keys 18
User LED’s 20
System LED’s 5
Interfaces
PC/Printer port See below
PLC port See below
Aux port (fieldbus and
Ethernet)
See below
Serial programming
speed
9600 – 38400 bps
Functionality
Vector graphics -
Dual driver capability -
Data acquisition and
trends
-
Recipe memory 16 KB
UniNet network Client/Server
Alarms 1024
Event list 256
Password Yes
Hardware RTC Yes, battery backed
Screen saver -
Buzzer -
Battery 3 V 270 mA Lithium, non
rechargeable, user
replaceable, model CR2430.
Replace with same component
or equivalent compatible with
the operating temperature of
the product.
Ratings
Power supply voltage 18 - 30 VDC
Current consumption ~ 300 mA at 24 VDC
Fuse Automatic
Weight ~ 0.5 Kg (not including cable)
Min thickness of cable 7 mm diameter
Max thickness of cable 11 mm diameter
Environmental
Conditions
Operating temperature
0 to 50 °C
EN 60068-2-14
Storage temperature
-20 to +70 °C
EN 60068-2-14
Operating and storage
humidity
5 – 85 % RH non-condensing
EN 60068-2-30
Vibrations
10 ÷ 57 Hz, 0,075 mm peak
57 ÷ 150 Hz, 1 G
EN 60068-2-6
Shock 50 g, 11 ms, 3 pulses per axis
EN 60068-2-27
Protection class IP65
EN 60529
Keyboard reliability > 3 million operations
EN 60529
Electromagnetic
Compatibility (EMC)
Emitted interference Class A
EN 55011
Immunity to radiated
radiofrequency
electromagnetic field
80 MHz ÷ 1 GHz, 10 V/m
EN 61000-4-3
900 MHz, 10V/m
ENV 50204
Immunity to conducted
disturbances inducted
by radiofrequency field
0.15 ÷ 80 MHz, 10 V
EN 61000-4-6
Fast transient 2 KV power supply
1 KV signal lines
EN 61000-4-4
Electrostatic discharge 8 KV in air
EN 61000-4-2
Dimensions
A 116 mm (4.56“)
B 86 mm (3.38“)
C 102 mm (4.01”)
D 239 mm (9.41”)
The product is designed for installation in industrial environments in compliance with the regulations:
Emitted interference EN 61000-6-4, 2001
Noise immunity EN 61000-6-2, 2001
All circuits in this handheld product, including the wiring of the emergency stop button and the
enabling switches, must be considered SELV circuits. They will have to be wired in compliance with
EN 60950.
