MANUGENEX7xx - Version 2.09

5 Connections

PLCM and PLIO03 electrical ratings:

- PLCM01: For electrical rating refers to the host eX700 models.

- PLCM05: For electrical rating refers to the host eX700 models and PLIO03 ratings

- PLCM09X: 2xDigital Inputs voltage 12÷30 Vdc, 3mA; 2xDigital Outputs voltage 12÷30 Vdc, 0.5A

- PLIO03: 20xDigital Inputs voltage 12÷30 Vdc; 12xDigital Outputs voltage 12÷30 Vdc, 0.5A; 4xAnalog

inputs 0÷10 Vdc, 4-20mA; 4xAnalog outputs: 0÷10 Vdc, 4-20mA

PLCM01 / PLCM01-NE: Operating temperature -20°C to 60°C

PLCM05: Operating temperature -20°C to 60°C

PLCM09X: Operating temperature -20°C to 60°C

PLIO03: with part number PLIO03xxxxY where:

- Y≤2 is operating temperature range 0°C≤Tamb≤+50°C with

Operating Temperature Code T5 (vertical installation), 12-30VDC

- Y>2 is operating temperature range –20°C≤Tamb≤+60°C with

Operating Temperature Code T4 (vertical installation), 12-30VDC

Below you can nd relation between modules ATEX and IECEx certied and max number of modules that can

be used into eX700 serie panels, based on their Interface Type:

Module Application Max Modules Interface Type

Bus Extension

connector

PLCM01 CAN 1 for eX705

2 for other panels

CAN Y

PLCM01-NE CAN 1 for eX705

2 for other panels

CAN N

PLCM05 CODESYS License 1 Y

PLCM09X 3G modem 1 Y

PLIO03 Multifunction I/O 1 SPI N

Note the above different “Operating Temperature Code” for different part number of PLIO03 module.
