Max modules refers to max number of modules can be plugged into the HMI (all slots).
If you are planning to use PLCM03 and PLCM04 (additional serial ports) you will obtain following “COM -
Slot#” association:
• a module plugged in Slot#1 or into Slot#2 will be COM2,
• a module plugged in Slot#3 or into Slot#4 will be COM3.
If you are planning to use two PLCM01 (CAN interface) you will obtain following Slot# association:
• a module plugged in Slot#1 or into Slot#2 will be the CanPort 0,
• a module plugged in Slot#3 or into Slot#4 will be the CanPort 1.
Below you can nd relation between modules and max number of modules that can be used into eX series
700 panels, based on their Interface Type:
Module Application Max Modules Interface Type
Bus Extension
connector
PLCM02 KNX 1 Serial
N
PLCM03 Serial RS232 2 Serial
Y
PLCM04 Serial RS485 2 Serial
Y
PLCM06 Probus DP 1 SPI
N
PLCM07 Ethernet 1 Ethernet
N
PLIO06 Compact I/O 2 SPI
N
5 Connections
