3.8 Illustration of the completed installation
Cautions:
1)Aftertheinstallationiscompleted,checkandbesurethatnotubingorconnectionsleakwaterduringushingprocess.
2) The drain water outlet tubing must be connected to the drain and secured properly. Do not use a water storage device to
collectthedrainwaterincasewaterspillsduetotheproduct’sautonomousush.
The RO Faucet may be in󰍰alled on any at surface. Check the underside of your
in󰍰all location for any interference by making sure that drilling a hole will not
damage any pipes or wiring underneath the countertop or sink. Check to be sure
there is enough room for the Threaded Faucet Stem.
NOTE! For drilling you mu󰍰 use an appropriate drill bit and drilling method
for the material of your sink and counter top. Dierent drill bits are required for
󰍰ainless 󰍰eel, porcelain, granite, etc.
You may use an exi󰍰ing hole in your counter or sink or drill a new hole (if using
an exi󰍰ing hole begin at 󰍰ep 2). Make sure the Base Plate is big enough to cover
the hole you use.
Porcelain Sink
A proper porcelain ½” drill bit is 󰍰rongly recommended to prevent chipping
if you are drilling on a porcelain sink. Drill slowly to avoid chipping during the
initial cutting of the porcelain.
Stainless Steel Sink
1. Use a proper ½” drill bit (depending on your sink / counter material) to make
a hole for your RO Faucet.
2. Insert the Pre-Assembled Base Plate & Rubber Washer (see design) onto the
Threaded Faucet Stem at the base of the RO Faucet. Then put the Threaded
Faucet Stem through the newly drilled or pre-exi󰍰ing hole. Make sure the RO
Faucet sits in the center of your new or exi󰍰ing hole.
3. Under the sink in󰍰all the Rubber Washer and the Tension Hand Screw (see
design) onto the Threaded Faucet Stem. Make sure they are in󰍰alled all the way
up the 󰍰em.
4. Attach the Union Connector to the Threaded Faucet Stem, and then insert the
¼” White Tube into the Union Connector.
Open&ClosedPosition
Closed Open
Counter Top
⅜”tubing(white)
(connect to water inlet port)
¼” tubing (white)
- connect to pure
water port
Power plug
¼” tubing (red)
(connect to waste
water port)
Hot Cold
3.7 Faucet installation
Pre-Assembled Base
Plate&RubberWasher
Rubber Washer
Union Connector
TensionHandScrew
Threaded Faucet Stem
¼” White Color Tube
NOTE: Make sure all tubing and connections are secured properly before turning on the water supply to the system.
RO Faucet
Drain
Drain
saddle
