GENERAL SETUP PROCEDURES
24
If the Memory Lock function is set to ON, the Memory selection Menu will be
disabled when in the Lock Mode. If the Memory Lock is set to OFF, the Memory
selection Menu will be enabled when in the Lock Mode. Different memories can be
recalled but the test parameters or steps cannot be changed. The Memory Lock
default is preset to ON at the factory. Please refer to the System Parameter Setup
section to set the Memory Lock mode.
6.3 Memory Configuration
Each memory location contains 8 separate steps which can be connected
sequentially to the next consecutive step. The following memory map illustrates
the separate locations for each step within each memory.
Memory map
Memory 0 Step 1 Step 2
. . . .
Step 8
Memory 1 Step 1 Step 2
. . . .
Step 8
.
.
.
Memory 9 Step 1 Step 2
. . . .
Step 8
6.4 Memory Program
Press the NUMERIC Keys 0-9 to enter the Memory location number. The program
will recall the test parameters stored in this location and the instrument will
respond with a short beep tone.
6.5 Step
Press the STEP key, the display will show the test parameters selected for that step.
Pressing the step key again will advance to the next step in sequence with step 1
following step 8.
Note: When the steps have been interconnected you will see an underbar character
on the display just after the step number. This indicates that the step after the active
step will run immediately after the active step is completed. The display will show:
XXX.X s A XXX.X V
M5-1
_
G-L XXX.X
µ
A
