Extech Instruments 382252 User Manual

382252-en-GB_V1.5 1/17
3
Meter Description
1. Digital Display – See Display Description below
2. HOLD key – Freezes measurement value on display
3. Zero ADJ control- Adjusts Zero value on display
4. Backlight key – Turns on Backlight
5. TEST key – Enables Earth Resistance and Earth
Voltage Tests
6. Function Selector switch – Selects desired range and
function
Top View
1. VC Input (Red)
2. P Input (Yellow)
3. COM / E Input (Green)
Display Description
1. Test status Icon
2. Battery Charge indicator -
3. Voltage Unit indicator
4. Audible Signal Icon
5. kUnits Indicators
6. Measurement Value
7. AC/DC Voltage Indicators
8. Low Battery Icon
9. HOLD Icon
12
3
4
5
7
8
9
6
12 3
1
2
3
4
5
6

Extech Instruments 382252 Specifications

General

Brand	Extech Instruments
Model	382252
Category	Test Equipment
Language	English
