Extech Instruments EX650 User Manual

EX65x‐en‐GB_V1.6 7/16
29
DCAZERO(EX655only)
The DC ZERO feature removes any offset values and improves the accuracy for DC current
measurements.
1. Turn the function switch to the
position and use the M button to select DC.
2. Ensure that there is no conductor in the clamp jaws.
3. Press the ZERO button; the delta symbol will appear and the display will zero.
4. Take a DC Current reading as described earlier in this guide.
5. Press the ZERO button to exit the DC Zero mode; the delta symbol will switch off.
MAX‐MINMode
In MAX‐MIN mode, the meter captures and displays the Maximum and Minimum readings
and updates only when a higher or lower value is registered.
1. Press the MAXMIN button to access this mode.
2.
The MAX icon will appear and the displayed reading will represent the highest
reading encountered since the MAXMIN button was first pressed.
3.
Press the MAXMIN button again. The MIN icon will appear and the displayed reading
will represent the lowest reading encountered since the MAXMINbutton was first
pressed.
4.
Continue to use the MAXMIN button to step through the MAX and MIN readings as
desired.
5.
Press and hold the MAXMIN button for 2 seconds to exit this mode (the MAX and
MIN icons should now be off). The meter will return to normal operation and the
MAX and MIN memories will be reset.
