EX65x‐en‐GB_V1.6 7/16
35
GENERALSPECIFCATIONS
Display 6000‐count Multi‐Function LCD
Polarity Automatic display of positive and negative polarity
Over‐rangeindication “OL” or “‐OL” is displayed
Conversionrate 3 updates per second
ClampSensorType Coil induction (EX650); Hall Effect (EX655)
Testpositionerror Additional error of ±1.0% of reading applies when the conductor
under test is not positioned at the center of the clamp head for
current measurements
Max.JawOpening 30mm diameter
Electromagneticfieldinfluence
Unstable or inaccurate readings may be displayed if there is an
electromagnetic field disturbance in the measurement environment
MaximumVoltage 750VAC RMS or 1000V DC maximum applied to any terminal
Lowbatteryindication
is displayed
AutoPowerOFF After 20 minutes (can be disabled by holding the M (MODE) button
while turning the meter ON)
OperatingTemperatureandHumidity
0~30C (32~86F); 80%RH maximum
30~40C (86~104F); 75%RH maximum
40~50C (104~122F); 45%RH maximum
StorageTemperatureandHumidity
‐20~60C (‐4~140F); 80%RH maximum (with battery removed)
OperatingAltitude 2000m (6562’)
Batterypower 3 x 1.5V ‘AAA’ alkaline batteries
Weight 270g (9.5 oz.) Including batteries
Dimensions (W x H x D) 75 x 223 x 40mm (2.9 x 8.7 x 1.6”)
SafetyStandards Complies with EN61010‐1, EN61010‐2‐032, and EN61010‐2‐033
CAT II 1000V, CAT III 600V; Pollution Degree 2
EMC EN61326‐1
ShockandVibration Sinusoidal vibration MIL‐PRF‐28800F (5~55 Hz, 3g max.)
DropProtection 1m (approx. 3’) drop onto hardwood on concrete flooring
ForIndoorUse
Copyright©2015‐2016FLIRSystems,Inc.
All rights reserved including the right of reproduction in whole or in part in any form
ISO‐9001Certified
