HD750-en-GB_V1.8 4/15
4
Basic Operation
Meter Power
The HD750 uses a 9V battery for power. If the meter does not switch on when the POWER
button is pressed or if the display shows BAT, replace the battery.
When the POWER buttons is pressed, the meter performs a short self test and reverts to the
settings in place when the meter was last turned off.
Automatic Power off Feature
In order to conserve battery life, the meter has an automatic power off feature (after 20
minutes). To defeat this feature, press and hold the HOLD button while turning the meter on.
Release the HOLD button when
n appears on the display. The meter will now remain on until
the user turns it off or until the battery weakens. Note that the Auto Power OFF feature will be
reactivated the next time the meter is turned off and then on.
Unit of Measure
Press the UNIT button to select the unit of measure. This meter offers eleven (11) units of
measure as listed below.
Unit of Measure Display icon
Pounds per square inch psi
Inches of Mercury inHg
Milli bar mbar
Millimeters of Mercury mmHg
Kilo Pascals kPa
Kilograms per centimeter squared Kgcm
2
Inches of water inH
2
O
Feet of water ftH
2
O
Centimeters of water cmH
2
O
Bars Bar
Ounces per square inch ozin
2
Fittings Connection
Connect tubing to the P1, P2 (or both) input port(s). If both inputs are used (differential mode),
the meter displays a positive pressure reading if the P1 pressure is greater than P2 and a
negative reading if P2 is greater than P1.
