Description
MeterDescription

1. LCDDisplay
2. ControlButtons
3. Lanyard
4. Type‐KThermocoupleinputjack
5. Batterycompartment(9V)
6. MeasurementTrigger
7. IRThermometerlens
8. Ambienttemperaturesensor
9. Laserpointerlens
DisplayDescription




Largedigitsatcenterforprimarymeasurementvalue

SmalldigitsatlowerrightforMAX‐MIN‐AVG‐DIFvalues

SmalldigitsatlowerleftforEmissivity value

Emissivityvalueindication

Laserpointeractive
S
Scanmode(activewhilethetriggerispulled;displayedtemperature
tracksthetemperatureofthescannedsurfaces)
H
Holdmode(displayedtemperaturefreezeswithtriggerrelease)
MaxMinAvgDiff Maximum/Minimum/Average/Differentialtemperaturereadings

Batterycapacityindicator(flasheswhenbatteryvoltageiscritical)
KAO
K/A/OTemperaturemeasurementtypes:
K:Thermocouple,A:Ambient,O:Object/Surface

Temperatureunits(°F/°C)
AlmHL HighandLowTemperatureAlarms
1
2
3
4
5
6
7
8
9
