Extech Instruments MultiView Series User Manual

Specifications
General Specifications
Display 1999 count 3 1/2 digit, adjustable angle (MV-110, MV-120)
19999 count 4 1/2 digit, adjustable display (MV-130)
Sample Rate Approximately 2 - 3 per second
Input warning Alarm sounds with test leads in the A or 10A socket and the wrong function is selected.
Fuse Protection 2A (A socket), 0.2A (mA socket), 10A or 20A range not fused
Power Supply 9V battery (NEDA 1604 or equivalent)
Range selection Manual
Over-range Indication "1"
Auto Off Unit switches off after 15 minutes of inactivity
Low Battery Indication battery symbol
Operating Temperature /
Humidity
32
0
F to 104
0
F (0
0
C to 40
0
C) / < 75% RH
Storage Temperature 14
0
F to 122
0
F (-10
0
C to 50
0
C)
Dimension / Weight 7.3 x 3.5 x 1.3" (185x89x32mm) LxWxH / approx. 9.7 oz. (300 grams)
