Extech Instruments MultiView Series User Manual

Electrical Specifications
Function
(model)
Range Accuracy
% Rdg. + digits
Resolution Input
Protection
Comments
200mV 0.1mV 250V rms
2, 20, 200V
±(0.5% + 1 digit)\
0.001,0.01,0.1V
DCV
(MV-110, MV-120)
1000V ±(0.8% + 2 digit) 1V
1000VDC
750VAC
200mV 0.01mV 250V rms
2, 20, 200V
±(0.05% + 3digits)
0.0001,0.001,0.01V
DCV
(MV-130)
1000V ±(0.1%+ 5 digits) 0.1V
1000VDC
750VAC
Input impedance > 10M
Ω
200mV ±(1.2% + 3 digits) 0.1V
2, 20, 200V ±(0.8% + 3 digits) 0.001,0.01,0.1V
ACV
(MV-110, MV-120)
750V ±(1.2% + 3 digits) 1V
1000VDC
750VAC
2, 20, 200V ±(0.8% + 10 digits) 0.0001,0.001,0.01V ACV
(MV-130)
750V ±(1.0% + 15 digits) 0.1V
1000VDC
750VAC
Input impedance > 1M
Ω
Frequency range:
<200V: 40 to 400Hz, < 750V: 40 to 200Hz
20µA
±(2.0% + 5 digits)
0.01µA
200µA, 2, 20 mA
±(0.8% + 1 digits)
0.1µA, 0.001,0.01mA
200mA, 2A ±(1.2% + 1 digits) 0.1mA, 0.001A
2A,250V fuse
DCA
(MV-110)
10A ±(2.0% + 5 digits) 0.01A not fused
20, 200 mA ±(0.8% + 1 digits) 0.01, 0.1mA 0.2A,250V fuse DCA
(MV-120)
20A ±(2.0% + 5 digits) 0.01A not fused
15 sec. max @ 20A
