7 PRC15-en-US_V1.5 03/21
Tilt Stand / Hanger
The rear stand provides two methods for viewing convenience.
1. Pull the bottom portion of the stand out to place the unit on a flat surface for viewing.
2. Pull the bottom and top portions of the stand out, and then rotate the stand to allow the unit
to be hung.
Battery Replacement
When the battery icon appears on the display, the six AA batteries must be replaced.
The battery compartment is located on the rear of the meter.
1. Open the tilt stand, loosen the captive Philips head screw and remove the battery cover.
2. Remove and replace the batteries, observing polarity.
3. Replace and secure the battery cover.
Safety: Please dispose of batteries responsibly; never dispose of batteries in a fire, batteries may
explode or leak. If the meter is not to be used for 60 days or more, remove the battery and
store separately
