Extech Instruments PRC15 User Manual

8 PRC15-en-US_V1.5 03/21
Specifications
General Specifications
Display Dot matrix LCD
Maximum Load 1000 ohms @ 24mA
Meter Power 6 AA batteries or AC adaptor
Auto Power OFF Meter automatically powers off after 10 minutes of inactivity
Current output capability 24mADC at 1000 ohms
Voltage input impedance 10kohms minimum
Operating Temperature 41ºF to 104ºF (5ºC to 40ºC)
Storage Temperature - 4
o
F to 140
o
F (5ºC to 40ºC)
Operating Humidity Max 80% up to 87ºF (31ºC) decreasing linearly to 50% at 104ºF
(40ºC)
Storage Humidity <80%
Operating Altitude 7000ft (2000meters) maximum
Dimensions 6.3 x 3.2 x 1.7") (159 x 80 x 44 mm)
Weight 8.3 oz. (234g)
Range Specifications
Mode
Function
Range (Resolution)
Accuracy (% of reading)
DC
Measure
Current
0 to 50mA (0.01mA)
± (0.01% + 1 digit)
Percent (%)
-25% to +230% (0.1%)
Voltage
(autorange)
0 to 1999mV (1mV)
2 to 20V (0.01V)
DC Source
Current
0 to 24mA (0.01mA)
Percent (%)
-25% to +125% (0.1%)
Voltage
0 to 2000mV (1mV)
0 to 20V (0.01V)
