Extech Instruments SDL600 User Manual

3 SDL600-EU-EN-V1.2-10/11
Getting Started
Accessories
• The SDL600 includes batteries, SD card, windscreen, and carry case. If items are missing
please contact the distributor through which this product was purchased
• An optional AC adaptor is available through Extech distributors
• Optional sound level calibrators are available through Extech distributors. Calibrators are highly
recommended for best accuracy and repeatability.
Power ON-OFF
• Press and hold the power button for at least 1.5 seconds to power ON the meter.
• Press and hold the power button for 1.5 seconds to power OFF the meter.
• This meter is powered by six (6) 1.5VDC ‘AA’ batteries or by optional AC adaptor. If the meter
will not switch ON please check that fresh batteries are installed in the rear battery compartment
or, in the case of the AC adaptor, check that the adaptor is connected correctly to the meter and
to an AC source.
Operation
Measurement Considerations
1. Wind blowing across the microphone increases the noise measurement. Use the supplied
windscreen to cover the microphone when applicable.
2. Calibrate the instrument before each use if possible. Especially if the meter has not been used
for a long period of time.
3. Do not store or operate the instrument in areas of high temperature or humidity.
4. Keep meter and microphone dry.
5. Avoid severe vibration. Protect the meter from impact. Do not drop it. Transport the meter in
the supplied case.
6. Remove the battery when the meter is to be stored for long periods of time.
Basic Operation
1. Turn the meter ON by pressing and holding the button for 1.5 seconds.
2. The meter defaults to AUTO RANGE, ‘A’ Frequency Weighting, and ‘FAST’ Time Response.
3. Select ‘A’ or ‘C” frequency weighting in the SETUP Mode.
4. Select ‘Fast’ or ‘Slow’ response time by pressing and holding the FUNCTION button. Release
the button when the desired setting is displayed. Note that the PEAK HOLD mode of operation
is also accessed in this way.
5. Hold the meter in hand or use the tripod mount to affix the meter in the desired location.
6. To select the range, press and hold the RANGE button until the desired range is shown
(AUTO, 30 to 80, 50 to 100, or 80 to 130db). Use a range that puts the sound level reading in
the center of the range. If dashes appear on the display select a new range if possible. Note
that the overall range of the instrument is 30 to 130 db.
7. The sound level reading is shown in large digits at the center of the LCD.
8. To turn the meter off, press and hold the button for 1.5 seconds.

Extech Instruments SDL600 Specifications

Display

display size	52 x 38mm (2 x 1.5”) Backlit LCD
display update rate	Approx. 1 second

Microphone

microphone type	12.7mm (0.5”) electret condenser microphone
microphone diameter	12.7mm (0.5”) outer diameter

Measurement

measurement units	Decibels
measurement ranges	30 to 80, 50 to 100, and 80 to 130dB
frequency range	31.5Hz to 8KHz

Power

power supply	Six (6) 1.5 VDC batteries (optional 9V AC adaptor)
power consumption (normal operation)	approx. 12mAdc
power consumption (backlight off, datalogging on)	approx. 51mAdc

Operating Environment

operating temperature	0 to 50°C (32 to 122°F)
operating humidity	85% R.H. max.
auto power off	After 10 minutes of inactivity (can be disabled)

Weight and Dimensions

weight	428g (0.94 lbs.) including batteries
main instrument dimensions	250 x 73 x 47.5mm (9.8 x 2.9 x 1.9”)
