Extech Instruments SDL900 User Manual

EXTECHINSTRUMENTS
3SDL9 00 ‐en‐GB_V1.45/15
4
1
2
3
4
5
6
9
7
8
10
11
12
13
MeterDescription

1. ProbeConnection
2. LCDDisplay
3. HOLDButton
4. POWERButton
5. SETButton
6. RANGE/UpArrowButton
7. FUNCTION/DownArrowButton
8. ENTER/LOGButton
9. MAX/MINButton
10. RS‐232OutputTerminal(Side)
11. ResetButton(Side)
12. DC9VPower
AdapterInputSocket(Side)
13. TiltstandandBatterycompartment(Back)











Probe
1. ProbeSensingHead
2. ProbeHandle
3. ProbePlug
4. ProbeHeadCover

1
2
3

Extech Instruments SDL900 Specifications

General

Brand	Extech Instruments
Model	SDL900
Category	Multimeter
Language	English
