Extra 200 - Airworthiness Limitations

2 - 14 Page Date: 20. April 2002
Pilot´s Operating Handbook
EXTRA 200
Section 2
Limitations
2.14.3 INSTRUMENT MARKINGS
AIRSPEED INDICATOR
green arc 60 KIAS (111 km/h) - 154 KIAS (285 km/h)
yellow arc 154 KIAS (285 km/h) - 217 KIAS (402 km/h)
red line 217 KIAS (402 km/h)
OIL PRESSURE INDICATOR
red line 25 Psi (172 kPa)
yellow arc 25 Psi (172 kPa) - 55 Psi (379 kPa)
green arc 55 Psi (379 kPa) - 90 Psi (621 kPa)
yellow arc 90 Psi (621 kPa) - 100Psi (689 kPa)
red line 100 Psi (689 kPa)
OIL TEMPERATURE INDICATOR
yellow arc <140°F
green arc 140°F - 210°F
yellow arc 210°F - 245°F
red line 245°F
CYLINDERHEAD TEMPERATURE INDICATOR
yellow arc <150°F
green arc 150°F - 400°F
yellow arc 400°F - 500°F
red line 500°F
RPM INDICATOR
green arc 700 - 2500 RPM
yellow arc 2500 - 2700 RPM
red line 2700 RPM
G - METER
green arc - 5 g - + 8 g
yellow arc + 8 g - + 10 g
red line + 10 g
FUEL PRESSURE INDICATOR
red line 0 PSI
green arc 0 PSI - 12 PSI
red line 12 PSI
FUEL CAPACITY INDICATOR "WING TANK"
red line 0
FUEL CAPACITY INDICATOR "ACRO & CENTER TANK"
yellow line 0
red line * 0
When the Fuel Capacity Indicator "ACRO & CENTER TANK" reads
"ZERO" in level flight the remaining usable fuel is 8 Liters (2 US GAL.)
* For the US. registred aircrafts only
NOTE
Page Date: 14. July 2008
