Extra 200 - Sample; Weight and Balance Record Sheet

Page Date: 20. April 2002 6 - 7
Section 6
Weight and Balance and Equipment List
Pilot´s Operating Handbook
EXTRA 200
Σ Σ
Σ Σ
Σ ( W x X )
ΣΣ
ΣΣ
Σ W
= _ _ _ cm
6.3.1 SAMPLE
Takeoff Condition:
Pilot On Rear Seat 90.0 kg ( 198.5 lbs)
Copilot On Front Seat 65.0 kg ( 143.3 lbs)
"Acro & Center" Fuel 25.9 kg ( 57.1 lbs)
86 l Fuel In Wing Tanks 62.0 kg ( 136.7 lbs)
Aircraft Empty Weight 567.0 kg (1250 lbs)
======== ==========
809.9 kg (1785.6 lbs)
To find C.G., follow line "Pilot Rear Seat" from Empty Weight to "90 kg" [198.5 lbs] (Point "1").
Continue on line "Copilot Front Seat" to 65 kg (Point "4"). Now follow line "Fuel" via Point "5"
to Point "6":
FIND: Weight ~ 810 kg (1785.7 lbs)
C.G. ~ 80.2 cm (31.5 inch)
6.3.2 WEIGHT AND BALANCE RECORD SHEET
WEIGHT ARM MOMENT
(Kg) (cm) (Kg cm)
EMPTY WEIGHT:
PILOT:
COPILOT:
"ACRO & CENTER" - FUEL:
"WING TANK" - FUEL:
Σ Σ
Σ Σ
Σ W =
Σ Σ
Σ Σ
Σ ( W x X ) =
XG =
