7 - 6 Page Date: 20. April 2002
Section 7
Description and Operation of Aircraft and Systems
Pilot´s Operating Handbook
EXTRA 200
7.6 INSTRUMENTATION
The EXTRA 200 is equipped with flight instruments in both cockpits.
Instruments and placards can be provided with markings in either metric or English units. The
colour markings in instruments follow US-FAR, part 23 recommendation ( see section 2 ).
7.6.1 INSTRUMENT PANEL (REAR COCKPIT)
For instrumet panel arrangement of the reat cockpit refer to Fig. 7.6.1, which includes
standard and optional equipment marked as such.
Fig. 7.6.1:
1 2 3 4 5 6
16 15 14 13 12 11 10 9 8 7
