Page Date: 20. April 2002 7 - 7
Section 7
Description and Operation of Aircraft and Systems
Pilot´s Operating Handbook
EXTRA 200
NOTE
Standard Optional Position Item
x 1 Magneto Selector switch & starter
x 2 Amperemeter
x 3 Airspeed indicator
x 4 Magn. Direction indicator
x 5 g-meter
x 6 EGT / CHT
x 7 COM
x 8 Oil temperature
x 9 Oil pressure
x 10 RPM indicator
x 11 Manifold pressure
x 12 Altimeter
x 13 Switches / Circuit breaker
x 14 Fuel pressure
x 15 Fuel Quantity "Acro & Center" Tank
x 16 Fuel Quantity "Wing Tank"
x 17 Vertical speed indicator
x 18 Turn and bank indicator
x 19 Artificial horizon
x 20 Intercom button
x 21 Directional gyro
x 22 RPM control, Prop governor
x 23 Mixture control
x 24 Throttle lever
x 25 Stick
x 26 Radio button
x 27 Fuel shutoff valve
x 28 Trim lever and indicator
x 29 Boost pump
This list may be modified by the minimum equipment requirements of individual
certifying authorities!
