19AP-7622 Access Point Installation Guide
4
AP-7622 Access Point
Specifications
Electrical Characteristics
An AP-7622 has the following electrical characteristics:
Physical Characteristics
An AP-7622 Access Point has the following physical characteristics:
Radio Characteristics
An AP-7622 Access Point has the following radio characteristics:
Operating Current &
Voltage
12VDC, 1A, 2.5mm barrel connector, center positive
Power over Ethernet 48VDC, .25A, PoE
Dimensions 7.1 in. L x 6.5 in. W x 1.6 in. H
180 mm L x 165 mm W x 41 mm H
Weight 0.85 lbs/0.385 kg
Operating Temperature 32° F to 104° F/0° C to 40° C
Storage Temperature -40° F to 158° F/-40° C to 70° C
Operating Humidity 85% RH non-condensing
Operating Altitude
(maximum)
8,000 ft @ 28C
Storage Altitude
(maximum)
30,000 ft
Electrostatic Discharge 15KV air, 8KV contact
Data Rates Supported 802.11b/g: 1,2,5.5,11,6,9,12,18,24,36,48 and 54 Mbps
802.11a: 6,9,12,18,24,36,48, and 54 Mbps
802.11n: MCS 0-15 up to 300 Mbps
802.11ac: MCS 0-9 up to 866.7 Mbps
Wireless Medium Direct Sequence Spread Spectrum (DSSS)
Orthogonal Frequency Division Multiplexing (OFDM)
Network Standards IEEE 802.11a/b/g/n/ac
802.11d and 802.11i WPA2
WMM and WMM-UAPSD
Transmit Power
Adjustment
1dB increments
