Extreme Networks AP305C Accessories Guide

Outdoor Mounting Accessory Installation
Install the Access Point on a Pole Using AH-ACC-STRP-MRN Accessory
on page 28
Install the Access Point on a Flat Surface Using AH-ACC-BKT-ASM Accessory
on page 30
Ground Connection on page 32
Learn about various outdoor mounting accessories that can be used to install the access point.
The outdoor mounting accessories can only be used with outdoor access points. The outdoor mounting
accessories must be purchased separately.
Install the Access Point on a Pole Using AH-ACC-STRP-MRN Accessory
Install the access point on a vertical or horizontal 3 in. to 7 in. diameter pole using the AH-ACC-STRP-
MRN accessory.
Before You Begin
The following hardware is required for installation the access point to a vertical pole or a horizontal pole:
• An access point (AP460C, or AP460S6C, or AP460S12C)
• Two AH-ACC-STRP-MRN accessory, which is an outdoor access point stainless steel hose strap for 3
in. to 7 in. diameter poles.
Tip
The best practice is to mount the access point to a pole with a minimum circumference of
3 in.
Important
You must provide your own cable clamps if you are mounting the access point to a pole
that is less than 3 in. or more than 7 in. in diameter.
Tip
The best practice is to use a stainless-steel cable clamp that is 0.5 in. (12.7 mm) wide.
• A flat-head slotted screwdriver to tighten the clamp screws.
28
Wi-Fi 6 (802.11ax) Access Points

Extreme Networks AP305C Specifications

General

Model	AP305C
Category	Wireless Access Point
Frequency Bands	2.4 GHz and 5 GHz
Antenna	Internal
Power over Ethernet (PoE)	Yes
MIMO	2x2:2
Wi-Fi Standards	802.11a/b/g/n/ac
Ethernet Ports	1 x 10/100/1000Base-T Ethernet port
Form Factor	Ceiling mount, Wall mount
PoE Support	802.3af/at
Security Features	WPA3, WPA2, WPA
Operating Temperature	0°C to 50°C (32°F to +122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity Range Operating	5% to 95% non-condensing
