Install the Access Point on a 9/16 in. Wide Ceiling Using AH-ACC-BKT-

AX-IL Accessory

Learn how to install any indoor access point on a 9/16 in. wide interlude ceiling tile using the AH-ACC-

BKT-AX-IL accessory.

Before You Begin

The following hardware is required to install the access point on a 9/16 in. wide interlude ceiling:

• An indoor access point

• One AH-ACC-BKT-AX-IL accessory

About This Task

The AH-ACC-BKT-AX-IL accessory is used on 9/16 in. wide Armstrong interlude ceiling rails. The

interlude ceiling grid artwork is printed on the back of the accessory for your reference.

Procedure

1. Remove the ceiling tiles.

2. Place the accessory on the ceiling rail in such a way that the accessory metal hinges are about 1/8

of a turn from the sides of the ceiling rail.

3. Push up gently and rotate the accessory clockwise until the hinges hook over the edge of the rail

and the white tabs click in place.

Note

There are two white tabs in the back of the accessory that holds on to the ceiling rail in

place. Use your ﬁnger to push and unhook one side of the white tab if you want to remove

the accessory from the ceiling rail.

Indoor Mounting Accessory Installation

Install the Access Point on a 9/16 in. Wide Ceiling Using

AH-ACC-BKT-AX-IL Accessory

Wi-Fi 6 (802.11ax) Access Points 15
