3. Using a slotted screwdriver, tighten the clamp screws to a minimum torque of 14 in-lbs. until the

access point is securely mounted onto the pole.

Figure 12: Access point pole mount positions

Callout Description

1 Vertically oriented access point mounted onto a pole

2 Horizontally oriented access point mounted onto a pole

3 Access point mounted onto a horizontal pole (indoor warehouse installation)

As an added security measure, you can thread a safety strap through one of the cable clamp slots in

addition to the cable clamps. Connect the other end of the strap to a secure object.

Important

The access point LAN glands must face down to eliminate water from entering the chassis.

Install the Access Point on a Flat Surface Using AH-ACC-BKT-ASM

Accessory

Install the access point on a vertical or horizontal outdoor ﬂat surface using the AH-ACC-BKT-ASM

accessory.

Before You Begin

The following hardware is required to install the access point to a ﬂat surface:

• An access point (AP460C, or AP460S6C, or AP460S12C)

• AH-ACC-BKT-ASM wall accessory (must be purchased separately)

• Four M5 bolts

• Four wall mount screws and screw-in anchors (must be provided by the installer)

Install the Access Point on a Flat Surface Using AH-

ACC-BKT-ASM Accessory Outdoor Mounting Accessory Installation

30 Wi-Fi 6 (802.11ax) Access Points
