Install the Access Point on a Standard Ceiling Rail
Install the access point on a 15/16 in. standard ceiling rail using the in-built bracket.
Before You Begin
Hardware required for ceiling rail installation:
• An AP305C/CX access point
About This Task
The AP305C/CX access point has a built-in bracket in the back of the access point that is used to install
the access point to a standard 15/16 in. dropped ceiling grid. For non-standard ceiling rail installations,
see Non-Standard Ceiling Grid or Wall Installation on page 16.
Procedure
1. Place the in-build bracket on a 15/16 in. ceiling grid.
2. Rotate the access point to 1/8
th
of a turn until it clicks into place.
Figure 4: Built-in brackets for standard ceiling grid mounting
Callout Description
1 Built-in bracket in the back of the access point
Install the Access Point Install the Access Point on a Standard Ceiling Rail
ExtremeWireless™ AP305C/CX Access Points 15

Extreme Networks ExtremeWireless AP305C Specifications

General

Model	AP305C
Category	Wireless Access Point
Frequency Bands	2.4 GHz, 5 GHz
Antenna Type	Internal
PoE	802.3af/at
MIMO	2x2:2
Mounting	Ceiling, Wall
Operating Humidity	5% to 95% non-condensing
Security	WPA3, WPA2, WPA
Management	ExtremeCloud IQ, SNMP, CLI
Operating Temperature	0°C to +50°C (32°F to +122°F)
