External Antenna Configuration
Information
Details about antenna gain, external antenna configuration, and antenna radio port support.
Antenna gain
Wi-Fi/BLE antenna AP305C (maxinum antenna
gain)
AP305CX (maximum antenna
gain)
2.4 GHz 2.7 dBi 3.0 dBi
5.0 GHz 4.0 dBi 5.0 dBi
External antenna information
The AP305CX access point comes with four external antenna connectors and is compatible with the
ML-2452-APA2-02 and AH-ACC-ANT-AX-KT antennas.
Note
The ML-2452-APA2-02 and AH-ACC-ANT-AX-KT antennas must be purchased separately.
20 ExtremeWireless™ AP305C/CX Access Points

Extreme Networks ExtremeWireless AP305C Specifications

General

Model	AP305C
Category	Wireless Access Point
Frequency Bands	2.4 GHz, 5 GHz
Antenna Type	Internal
PoE	802.3af/at
MIMO	2x2:2
Mounting	Ceiling, Wall
Operating Humidity	5% to 95% non-condensing
Security	WPA3, WPA2, WPA
Management	ExtremeCloud IQ, SNMP, CLI
Operating Temperature	0°C to +50°C (32°F to +122°F)
