• One safety hanger provision
• One USB 2.0 type A connector
• Power: PoE at 802.3at and 802.3bt (see AP310i/e Power Source for details)
• Antennas:
◦ AP310i: Four Wi-Fi internal antennas and one BLE internal antenna
◦ AP310e: Four RP-SMA external antenna ports and one BLE RP-SMA antenna
• Temperature:
◦ AP310i: 0°C to +50°C (32°F to +122°F)
◦ AP310e: -20°C to +55°C (-4°F to +131°F)
• Enclosure: Plastic
AP310i/e Power Source
Power source Description
Power over Ethernet (PoE) Power is provided through the 1G Ethernet port of
AP310i/e, c
ompliant to be powered with 802.3at
and 802.3bt to provide full functionality. For
reduced functionality, use 802.3af.
PoE out PoE power source is available on GE2 port when
the input power is at 802.3at.
External 12V DC power supply (optional; ordering
part #37219- PWR 12VDC, 3A, 2.5mm x 5.5mm
connector)
Power is provided through an external DC power
supply plugged into an AC source.
Note
P
oE is disabled when external power supply is used.
AP310i/e Power Tables
Table 4: AP310i power table
AP310i 802.3af 802.3at and DC
Radio 0 (sensor) 2.4G – 2×2 (20dBm)
5G – 2×2 (19dBm)
2.4G – 2×2 (20dBm)
5G – 2×2 (19dBm)
Radio 0 (2.4G) 2×2 (20dBm) 2×2 (20dBm)
Radio 0 (5G–L) 2×2 (18dBm) 2×2 (18dBm)
Radio 1 (5G–F) 2×2 (20dBm) 2×2 (20dBm)
Radio 1 (5G–H) 2×2 (18dBm) 2×2 (18dBm)
BLE On On
USB O On
PSE O On
AP310i/e Power Source Product Overview
10 ExtremeWireless™ AP310i/e Access Points
