• #37201, stainless-steel main mounting bracket with #37210, flat metal easy-attach adapter
• Phillips pan head screws
Tip
T
he best practice is to install the access point using the mounting brackets.
Install the Access Point Using the Main Mounting Bracket
About T
his Task
The main mounting bracket is a stainless-steel bracket that ships with the access point. It is used during
drywall or wood wall installation, or solid flat ceiling installation.
Tip
T
he best practice is to use the main mounting bracket for all wall installations.
Procedure
1.
Using the mounting bracket as a template, mark and drill two hole centers on the wall.
Note
T
he bracket feet must be pointing up.
Install the Access Point Using the Main Mounting
Br
acket Install the Access Point
