Install the Access Point on a Flat T-bar Using Main Mounting Bracket
Before You Begin
Ensure that the T-bar meets the following conditions before installing the main mounting bracket on a
flat T-bar:
• T-bar width must be 15/16 in. (24 mm).
• T-bar bottom must be flat, all the way across the ceiling.
• T-bar must be structurally sound.
• T-bar maximum base thickness must not exceed 0.055 in. (1.4 mm).
• Ceiling tile over the T-bar must be flat, all the way across.
About This Task
The main mounting bracket is used on a T-bar when the ceiling model is a suspended or drop ceiling
and when there is a T-bar on the ceiling.
Procedure
1. Remove the ceiling tiles.
Install the Access Point on a Flat T-bar Using Main
Mounting Bracket Install the Access Point
22 ExtremeWireless™ AP310i/e Access Points
