Install the Access Point on a Flat T-bar Using Main Mounting Bracket and
KT-135628-01 Adapter
Before You Begin
Ensure that the T-bar meets the following conditions before installing the main mounting bracket with
the KT-135628-01 adapter on a T-bar:
T-bar width can be either 9/16 in. (15 mm) or 15/16 in. (24 mm).
T-bar bottom must be flat all the way across.
T-bar must be structurally sound.
T-bar maximum base thickness must not exceed 0.055 in. (1.4 mm).
Due to manufacturing variation, some adapters can accommodate up to 0.060 in. (1.5 mm).
Ceiling tile may protrude up to 0.35 in. (8.89 mm) below the T-bar.
About This Task
If the ceiling tile is not flat and has a protrusion, use the main mounting bracket with the KT-135628-01
adapter. Attach the adapter to the main mounting bracket before attaching the bracket to a T-bar.
Procedure
1. Attach the T-bar adapter to the main mounting bracket by lining up the small bends on the adapter
with the long raised parts on the main bracket.
2. Pull up the KT-135628-01 adapter locking pin, and twist.
Ensure that the locking pin goes into the locking pin hole on the main bracket and locks in place.
Install the Access Point on a Flat T-bar Using Main
Mounting Bracket and KT-135628-01 Adapter Install the Access Point
24 ExtremeWireless™ AP310i/e Access Points
DRAFT
