Extreme Networks ExtremeWireless AP460C User Manual

Antenna Gain Information
Information about the dual-band and dual 5G antenna gain information on AP460C, AP460S6C, and
AP460S12C access points.
Table 10: AP460C access point antenna gain
Software mode 2×2 radio
WiFi0
4×4 radio
WiFi1
Scanner
WiFi2
IoT radio Azimuth
beamwidth
Elevation
beamwidth
Dual-band 2.4 GHz 3.24 dBi – 3.74 dBi 3.2 dBi 360° 150°
5 GHz – 4.21 dBi 3.42 dBi
Dual 5G 2.4 GHz – – 3.74 dBi 3.2 dBi 360° 150°
5 GHz 3.56 dBi 4.21 dBi 3.42 dBi
Table 11: AP460S6C access point antenna gain
Software mode WiFi0 WiFi1 WiFi2 IoT radio Azimuth
beamwidth
Elevation
beamwidth
Dual-band 2.4 GHz 7.88 dBi - 7.83 dBi 7.9 dBi 60° 60°
5 GHz - 8.06 dBi 6.46 dBi
Dual 5G 2.4 GHz - - 7.83 dBi 7.9 dBi 60° 60°
5 GHz 7.79 dBi 8.06 dBi 6.46 dBi
Table 12: AP460S12C access point antenna gain
Software mode WiFi0 WiFi1 WiFi2 IoT radios Azimuth
beamwidth
Elevation
beamwidth
Dual-band 2.4 GHz 7.12 dBi - 5.53 dBi 6.63 dBi 120° 70°
5 GHz - 6.25 dBi 5.54 dBi
Dual 5G 2.4 GHz - - 5.53 dBi 6.63 dBi 120° 70°
5 GHz 6.36 dBi 6.25 dBi 5.54 dBi
For antenna plot information, refer to the Wi-Fi6 802.11ax Antennas Specifications Guide.
