Overall Configuration Procedure for the Control Processor
Configure the IP settings of
the control processor and the
TouchLink Pro touchpanels.
See Network
Communication Setup
Create GUI layouts for the
touchpanels or other interfaces:
1. Start GUI Designer.
2. Create GUI layout designs for each
TouchLink Pro, third party
touchpanel (with a TouchLink
Interface), or a computer or
mobile device (with LinkLicense).
3. Save and build the GUI layout le.
Or...
Download existing GUI layouts
from identical touchpanels.
Create monitors, schedules, timers,
macros, and local variables.
Add touchpanels or other interfaces
(if used) to the project.
Congure ports on the
control processor.
Import GUI layouts and congure the
touchpanels or other interfaces.
Test the system, make adjustments,
nalize conguration.
Save the project.
Build and upload the conguration to
the control processor.
If desired or required, install a new
security certicate (via Toolbelt).
Will
TouchLink Pro or
third party touchpanels or
other user interfaces
be used?
No Yes
Create a new GC Professional or GC Plus project
and add the control processor to it.
Within Global Configurator
(GC Professional or
GC Plus mode):
Figure 7. Overall Configuration Steps
Network
Communication Setup
on page3.
For information on safety guidelines, regulatory compliances, EMI/EMF compatibility, accessibility, and related topics, see the
Extron Safety and Regulatory Compliance Guide on the Extron website.
