20XTP II CrossPoint Series • Front Panel Operations
Saving or Recalling a Preset
A "preset" is a conguration that has been stored.
1. Save a preset — Press and hold the Preset button until it
blinks.
PRESET PRESET
The Preset button blinks.
Press and hold.
2 seconds
Sa
ve a
preset
Recall a preset — Press and release the Preset button.
PRESET PRESET
1 2 3 4 5 6 16
15
Recall a
preset
The Preset button lights.Press and release.
All input and output buttons with assigned presets light red
.
When a preset is saved, the configuration data at
assigned preset locations is overwritten.
INPUTS
2. Press and release the desired input or output button.
1
ENTER
The button blinks
red
to indicate that
this preset is selected to save or recall.
The Enter button blinks
red
to indicate the need to
activate the save or recall.
3. Press and release the Enter button.
Setting the Front Panel Locks (Executive Modes)
The matrix switcher has three levels of front panel security lock
that limit the operation of the matrix switcher from the front panel.
The three levels are:
• Lock mode 0 — The front panel is completely unlocked.
• Lock mode 1 — All functions are locked from the front panel
(except for setting Lock mode 2). Some functions can be
viewed.
• Lock mode 2 — Basic functions are unlocked. Advanced
functions are locked and can be viewed only.
Basic functions consist of:
• Making ties
• Saving and recalling presets
• Setting input audio gain and attenuation
• Changing Lock modes
