36 XTP II CrossPoint Series • Remote Control
Command SIS Command
(Host to Unit)
Response (Unit to Host)
Additional Description
Information requests
Information request
I
V
X2&
X
X2*
•A
X2&
X
X2*]
In the response: V
X2&
X
X2*
is the video matrix size.
A
X2&
X
X2*
is the audio matrix size.
Request part number
N
X2(]
See the www.extron.com, for part numbers.
Request input/output board conguration
*N
X2(
.
X3)
1
X3)
2
...
X3)
n
X3!
1
X3!
2
...
X3!
n
]
Part number, dot, 4, 8, or 16 (
n
)
X3)
s; each is the input
board installed, starting from input slot 1, followed by 4, 8, or 16 (
n
)
X3!
s; each is the output board installed, starting
from output slot 1.
Example (XTP II CrossPoint 3200)
*N
Input:
Output:
Input slot 3 = XTP CP 4i HDMI
Output slot 7 = No Board
Input slot 6 = XTP CP 4i VGA Output slot 2 = XTP CP 4o (XTP)
1
2
345678
1
2
345678
60-nnnn-nn.GGHFXFIHDDDEJXXM
Query rmware version
Q
X3@]
Example:
Q
1.23
]
The factory-installed controller rmware version is 1.23 (sample value only).
NOTE: • = Space
X2&
= Number (quantity) of inputs 4, 8, 12, 16, 20, 24, 28, 32, 36, 40, 44, 48, 52, 56, 60, 64
X2*
= Number (quantity) of outputs 4, 8, 12, 16, 20, 24, 28, 32, 36, 40, 44, 48, 52, 56, 60, 64
X2(
= Part number 60-nnnn-01
X3)
= Installed input board A = XTP CP 4i 4K (TP) K = XTP CP 4i HDMI DMA
F = XTP CP 4i VGA N = XTP CP 4i Fiber 4K G = XTP CP 4i (TP) P = XTP CP 4i 3G-SDI H = XTP CP 4i HDMI S = XTP CP 4i HD 4K PLUS I = XTP CP 4i DVI Pro X = No board installed X3!
= Installed output board B = XTP CP 4o 4K (TP) M = XTP CP 4o SA (stereo audio)
D = XTP CP 4o (TP) O = XTP CP 4o Fiber 4K E = XTP CP 4o HDMI U = XTP CP 4o HD 4K PLUS J = XTP CP 4o DVI Pro X = No board installed X3@
= Firmware version number to second decimal place (x.xx)
