41XTP II CrossPoint Series • Remote Control
Command SIS Command
(Host to Unit to Endpoint)
Response (Endpoint to Unit to Host)
Additional Description
Relay controls
Turn on an endpoint relay
EX@
*
X3$
*1RELY
}
Rely
X@
*
X3$
*1
]
Turn on relay
X3$
in output
X@
.
Turn off an endpoint relay
EX@
*
X3$
*0RELY
}
Rely
X@
*
X3$
*0
]
Turn off relay
X3$
in output
X@
.
Toggle an endpoint relay
EX@
*
X3$
*2RELY
}
Rely
X@
*
X3$
*2
]
Toggle (on-to-off or off-to-on) relay
X3$
in output
X@
.
Pulse an endpoint relay
EX@
*
X3$
*3*
X3%
RELY
}
Rely
X@
*
X3$
*3*
X3%]
Turn on relay
X3$
in output
X@
for an interval dened
as
X3%
. Each step of
X3%
is 16 ms.
Example:
E
1*2*3*45RELY
}
Rely1*2*3*45
]
Turn on relay 2 in output endpoint 1 for 720 ms (0.72 sec,
X3%
= 45 * 16 ms = 720 ms).
View an endpoint relay status
EX@
*
X3$
RELY
} X3^]
On or off.
NOTE:
X@
= Output number 01 – 16, 32, or 64
X3$
= Relay on endpoint 1 or 2
X3%
= Pulse duration 0 through 65535 (each step = 16 ms, see the example above)
X3^
= Relay status 0 = Off 1 = On
