Ezviz H3c User Manual

1
Overview
1. Package Contents
Camera (x1)
Drilling Template (x1) Waterproof Kit (x1) Screw Kit (x1)
Power Adapter (x1)
Regulatory Information
(x2) Quick Start Guide (x1)
The power adapter's appearance is subject to the one you have bought.
2. Basics
Micro SD Card Slot
RESET Button
Adjusting Screw
Ethernet Port
Power Port

Ezviz H3c Specifications

General

Type	IP security camera
Virtual assistant	Amazon Alexa & Google Assistant
Placement supported	Outdoor
Connectivity technology	Wired & Wireless
Wide Dynamic Range (WDR)	Yes
Sensor type	CMOS
Optical sensor size	1/2.7 \
Minimum illumination	0.01 lx
LED type	IR
Night vision distance	30 m
Lens diameter	4 mm
Number of lenses	1
Total megapixels	- MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video formats supported	H.264, H.265
Noise reduction technology	3D noise reduction
Bluetooth	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channel bandwidth	20 MHz
Wi-Fi data rate (max)	144 Mbit/s
Ethernet interface type	Fast Ethernet
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Intelligent Video Surveillance (IVS) system features	Human detection
Form factor	Bullet
Mounting type	Wall
Product color	White
International Protection (IP) code	IP67
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	512 GB
Power source type	DC
Power consumption (max)	6 W
Sustainability certificates	CE, Federal Communications Commission (FCC), REACH, RoHS, UKCA, WEEE

Weight and Dimensions

Length	157 mm
Weight	250 g
Diameter	72 mm
Package depth	100 mm
Package width	227 mm
Package height	92 mm
Package weight	447 g
