Ezviz H3c User Manual

4
3. Add camera to EZVIZ.
- Log in to your account using the EZVIZ app.
- On the Home screen, tap “+” on the upper-right corner to go to the Scan QR
Code interface.
- Scan the QR code on the Quick Start Guide cover or on the body of the camera.
Scan QR Code
- Follow the EZVIZ app wizard to add the camera to EZVIZ.
• Please choose to connect your camera to the Wi-Fi to which your mobile phone
has connected.
• The band of the Wi-Fi must be 2.4 GHz.
Press and hold the reset button for about 4s, and you can restart the camera and
restore all parameters to default.
Press and hold the reset button for about 4s in any of the following cases:
• The camera fails to connect to your Wi-Fi network.
• You want to connect the camera to another Wi-Fi network.
Installation
1. Micro SD Card Installation (Optional)
1. Remove the cover on the camera.
2. Insert the micro SD card (sold separately) into the card slot.
3. Place the cover back on.
After installing the micro SD card, you should initialize the card in the EZVIZ app
before using it.
4. In the EZVIZ app, tap the Storage Status in the Device Settings interface to
check the SD card status.
5. If the memory card status displays as Uninitialized, tap to initialize it.
The status will then change to Normal and then videos can be stored.

Ezviz H3c Specifications

General

Type	IP security camera
Virtual assistant	Amazon Alexa & Google Assistant
Placement supported	Outdoor
Connectivity technology	Wired & Wireless
Wide Dynamic Range (WDR)	Yes
Sensor type	CMOS
Optical sensor size	1/2.7 \
Minimum illumination	0.01 lx
LED type	IR
Night vision distance	30 m
Lens diameter	4 mm
Number of lenses	1
Total megapixels	- MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video formats supported	H.264, H.265
Noise reduction technology	3D noise reduction
Bluetooth	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channel bandwidth	20 MHz
Wi-Fi data rate (max)	144 Mbit/s
Ethernet interface type	Fast Ethernet
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Intelligent Video Surveillance (IVS) system features	Human detection
Form factor	Bullet
Mounting type	Wall
Product color	White
International Protection (IP) code	IP67
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	512 GB
Power source type	DC
Power consumption (max)	6 W
Sustainability certificates	CE, Federal Communications Commission (FCC), REACH, RoHS, UKCA, WEEE

Weight and Dimensions

Length	157 mm
Weight	250 g
Diameter	72 mm
Package depth	100 mm
Package width	227 mm
Package height	92 mm
Package weight	447 g
