Ezviz H3c User Manual

2
Lens
IR Light
LED Indicator
MIC
Name Description
RESET
Button
When the camera is working, press and hold for about 4s until the LED
indicator is solid red, and all parameters will be restored to default
settings.
LED
Indicator
Solid Red: Camera starting up.
Slow-ashing Red: Network exception.
Fast-ashing Red: Camera exception (e.g. Micro SD card
error).
Solid Blue: App visiting camera.
Slow-ashing Blue: Camera running properly.
Fast-ashing Blue: Camera ready for Wi-Fi connection.
Get the EZVIZ App
1. Connect your mobile phone to Wi-Fi (suggested).
2. Download and install the EZVIZ app by searching for “EZVIZ” in the App Store
or Google Play
TM
.
3. Launch the app and register an EZVIZ user account.
EZVIZ App
If you have already used the app, please make sure that it is the latest version. To nd
out if an update is available, go to the app store and search for "EZVIZ".
Connect to the Internet
• Wired Connection: Connect the camera to a router. Refer to Option A.
• Wireless Connection: Connect the camera to Wi-Fi. Refer to Option B.
1. Option A: Wired Connection
1. Connect the power adapter cable to the camera’s power port.
2. Plug the power adapter into an electrical outlet.
• Use power adapter and power cable come with the camera in the box.
• The LED turning fast-ashing blue indicates that the camera is powered on and ready
for network conguration.
3. Connect the camera to the LAN port of your router with the Ethernet cable
(purchase separately).
The LED turning slow-flashing blue indicates that the camera is connected to the
Internet

Ezviz H3c Specifications

General

Type	IP security camera
Virtual assistant	Amazon Alexa & Google Assistant
Placement supported	Outdoor
Connectivity technology	Wired & Wireless
Wide Dynamic Range (WDR)	Yes
Sensor type	CMOS
Optical sensor size	1/2.7 \
Minimum illumination	0.01 lx
LED type	IR
Night vision distance	30 m
Lens diameter	4 mm
Number of lenses	1
Total megapixels	- MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video formats supported	H.264, H.265
Noise reduction technology	3D noise reduction
Bluetooth	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channel bandwidth	20 MHz
Wi-Fi data rate (max)	144 Mbit/s
Ethernet interface type	Fast Ethernet
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Intelligent Video Surveillance (IVS) system features	Human detection
Form factor	Bullet
Mounting type	Wall
Product color	White
International Protection (IP) code	IP67
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	512 GB
Power source type	DC
Power consumption (max)	6 W
Sustainability certificates	CE, Federal Communications Commission (FCC), REACH, RoHS, UKCA, WEEE

Weight and Dimensions

Length	157 mm
Weight	250 g
Diameter	72 mm
Package depth	100 mm
Package width	227 mm
Package height	92 mm
Package weight	447 g
