Ezviz H3c User Manual

3
Power Adapter
DC12V 1A
Outlet
Router
4. Add your camera to EZVIZ.
- Log in to your account using the EZVIZ app.
- On the Home screen, tap “+” on the upper-right corner to go to the Scan QR
Code interface.
- Scan the QR code on the Quick Start Guide cover or on the body of the camera.
Scan QR Code
- Follow the EZVIZ app wizard to add the camera to the app.
2. Option B: Wireless Connection
1. Connect the power adapter cable to the camera’s power port.
2. Plug the power adapter into an electrical outlet.
• Use power adapter and power cable come with the camera in the box.
• The LED turning fast-ashing blue indicates that the camera is powered on and ready
for network conguration.
Power Adapter
DC12V 1A
Outlet

Ezviz H3c Specifications

General

Type	IP security camera
Virtual assistant	Amazon Alexa & Google Assistant
Placement supported	Outdoor
Connectivity technology	Wired & Wireless
Wide Dynamic Range (WDR)	Yes
Sensor type	CMOS
Optical sensor size	1/2.7 \
Minimum illumination	0.01 lx
LED type	IR
Night vision distance	30 m
Lens diameter	4 mm
Number of lenses	1
Total megapixels	- MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video formats supported	H.264, H.265
Noise reduction technology	3D noise reduction
Bluetooth	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channel bandwidth	20 MHz
Wi-Fi data rate (max)	144 Mbit/s
Ethernet interface type	Fast Ethernet
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Intelligent Video Surveillance (IVS) system features	Human detection
Form factor	Bullet
Mounting type	Wall
Product color	White
International Protection (IP) code	IP67
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	512 GB
Power source type	DC
Power consumption (max)	6 W
Sustainability certificates	CE, Federal Communications Commission (FCC), REACH, RoHS, UKCA, WEEE

Weight and Dimensions

Length	157 mm
Weight	250 g
Diameter	72 mm
Package depth	100 mm
Package width	227 mm
Package height	92 mm
Package weight	447 g
