Page #5 background image
E045 5 732786 - Rev.C
ENGLISH
CONTROL BOARD E045
We thank you for having chosen one of our products. FAAC is certain that from it you will obtain
all the performance you require. All our products are the result of years of experience in the field of
automated systems.
1. TECHNICAL SPECIFICATIONS
PURPOSE: this control board has been designed and built to control swing-leaf gates for vehicle and
pedestrian access control.
During programming you can choose between dif
ferent function logics.
2 programming levels are available from the board (BASIC and ADVANCED), using buttons and LCD
display
.
Mains power supply
With power supply switching 230 V~ ± 15% ; 50/60Hz
Power absorbed from mains Stand By = 4W ; MAX about 800 W
MAX load for motors
800 W
Accessories power supply
24 V
"
MAX. accessories current
+24V MAX 500 mA BUS-2EASY MAX 500 mA
LOCK (FAAC) 12 V~ / 24 V
"
Operating ambient temperature
from -20°C to +55°C
Power supply safety fuses
F1 = F5 A
Work time
Self-learned through SETUP - (Max 4 min and 10 sec)
Pause time
Programmable (from 0 to 9 min and 50 sec)
Motor power
Programmable on 50 levels
Connector inputs
XF433/868 Module, USB
Terminal board inputs
Mains power supply, BUS-2EASY, OPEN-A, OPEN-B,
STOP
Terminal board outputs
Flashing lamp, Motors, Electric lock (LOCK), OUT1, Ac-
cessories power supply
Tab. Technical specifications
