FAAC E045 User Manual

E045 7 732786 - Rev.C
ENGLISH
LCD
Signalling/Programming display
SW1 “+/R1” Programming button
SW2 “-/R2” Programming button
SW3 “F” Programming button
DL7 “STOP” Input status control LED
DL8 “OP-B” Input status control LED
DL9 “OP-A” Input status control LED
DL10 “
USB ” Signalling LED
DL11 “
RADIO1-XF ” Signalling LED (OMNIDEC)
DL12 “ RADIO2-XF ” Signalling LED (OMNIDEC)
DL13 “ ERROR ” Error/alarm signalling LED
DL14
“BUS MON“BUS-2EASY diagnostic signalling LED
DL15 Device signalling LED to
BUS-2EASY ACTIVE
DL16 Microprocessor power presence LED
DL17 +24V
"
Accessories power supply presence LED
J1 230 V~ ± 15% Power supply connector
J2 Motors and flashing lamp power supply connector
J3 Input connector
J5
XF 433/ XF 868 (OMNIDEC) receiver module connector
Channel 1 - OPEN A (Total Opening)
Channel 2 - OPEN B (Partial Opening)
J8 HOST USB-A for Mass Memories connector
J9 +24V
"
Accessories power supply connector
J10
BUS-2EASY Device connector
J11 Indicator Light/ Electric Lock output connector
F1 Motor and power supply safety fuse

FAAC E045 Specifications

General

Brand	FAAC
Model	E045
Category	Control Unit
Language	English
