E1SL 18 532258 04 - Rev. E
8.
E2
I4
I3
I1
I2
OFF
8.
E1
OFF
OFF
S1
S2
OFF
Translation of the original instructions
EN GL IS H
ADVANCED Function
Default
o1
OUTPUT OUT1 configuration (J22)
6
no = not enabled
1 = GONG (NO)
2 = BOARD ERROR/FAULT (NO)
3 = battery operation (NO)
4 = EMERGENCY active (NO)
5 = SAFETIES TEST configured on I1, I2, I3, I4 (NC)
6 = DOOR NOT CLOSED (NO)
7 = DOOR OPEN (NO)
8 = DOOR MOVING (NO)
9 = LIGHT (NO)
10 = INTRUSION ACTIVE (NO)
11 = CLOSING SAFETY (NO)
12 = SAFETIES (NO)
13 = AIRSLIDE SP1 (NO)
14 = AIRSLIDE SP2 (NO)
15 = LOCK (NO)
16 = PROGRAMMING Simply Connect in PROGRESS
17 = TIMER active
18 = PEOPLE IN NUMBER (NO)
19 = TRAFFIC LIGHT EXT (NO)
20 = TRAFFIC LIGHT INT (NO
23 = LOW BATTERY
24 = NIGHT
o2
OUTPUT OUT2 configuration (J22) (see options
o1)
2
In
Inputs status The segments of the display corresponding to the input that is active light up
(see the figure)
St
Exit PROGRAMMING Allows you exit from programming and decide whether to save the changes.
Y = save , no = do not save
Press the F button to confirm. After exit, the display shows automation status (See
ST in Basic programming)
Y
INPUTS status
Shown on the Advanced Programming display, function
In
segment lit = input active
The central dot is always lit
(OFF = segment always off)
Manual Release Safeties TEST
